Air Pads,

Monitor’s Air Pad bin-aerator is a low-cost, rugged option for getting material to flow through your hopper. The Air Pad has an effective radius of 10” and is part of a row of Air Pads spaced on 12” centers, in most applications. An external mounting kit makes installation easy and efficient.

Evassers, Flo-Pad

The Evasser is a bin-aeration unit that will replace the noisy and damaging vibrators commonly used. Other units that use air to create material flow often have problems with clogging and material back-flow. The Evasser uses a neoprene boot that expands to release pressurized air, which has an effective radius of 12”, and contracts when the air supply is stopped, creating a seal to block the material from clogging the air outlet. The Flo-Pad is a row of Evassers, placed in multiple locations in the hopper, to create the most flow of material.

Silent Turbine Vibrators
High Frequency, Low Amplitude

Piston Vibrators
Low Frequency, High Amplitude

Eccentric Vibrators/Drives

Air Cannons

An Air Cannon consists of a high pressure tank storing compressed air (80 to 125 PSI) and a quick release piston valve that, on command, instantly releases compressed air into the bin or silo to fluidize material. An Air Cannon can be used to solve a variety of bin material flow problems:

ARCHING
Material sticks at the end or above the sloping section of the bin

RATHOLING
Material clings to sides of bin and creates a void or dead storage

BRIDGING
Material hangs in the lower sloping section of the bin

STICKING TO SIDES OF BIN
Material clings to the sides of the bin instead of flowing through the opening

Bolted Flat-Panel Silos, Welded Silos

> Return to main Component page

Bin Activators, Cone Valve Dischargers
